D5-300

Description



TerraMaster D5-300 5Bay

Super-fast RAID Storage with Multiple RAID Modes

Ideal for Photo and Video Storage

With its USB 3.1 high-speed interface, the easily operable D5-300 offers a storage capacity of over 90TB and supports multiple RAID modes. It is suitable for professionals who want to store photos, videos, or technical documents.

Achieve Super Speed with the USB 3.1 Protocol

Relying on the USB 3.1 Gen 1 super speed protocol, the D5-300’s transmission speeds can reach up to 220MB/s (Tested with Seagate IronWolf 4TB RAID 0).
Note: The USB 3.0 standard was renamed to USB3.1 Gen1 /USB3.2 Gen1 by the USB Implementers Forum (USB-IF) in 2015/2019 .

Cross-Platform Compatibility

Compatible with Windows, Mac, and Linux machines. No drivers needed!

Up to 100TB Storage Capacity

Equipped with 5 drive slots, supports a drive capacity of up to 20TB, and a total storage capacity of up to 100TB (Users need to purchase their own hard drives).

The Latest in USB Type-C Interface

The D5-300 adopts the latest USB Type-C interface, which is smaller in size, more reliable in connection, and more convenient to use than the previous generation.

Multiple RAID Modes

Supports multiple RAID modes: RAID 0, RAID 1, RAID 5, RAID 10, CLONE, JBOD, and Single Disk. Professionals can choose one or more according to their application scenarios.

Flexible and Reliable RAID Performance

Using a hardware RAID controller provides reliable and fast RAID performance, and there is also a specially customized RAID configuration client, which increases the simplicity and convenience of RAID management.

Multi-Drive Compatibility

Compatible with diverse 3.5-inch SATA hard drive brands and models, as well as with 2.5-inch SATA hard drives and SSDs.

Worry-Free Power Protection

To prevent damage to the device and hard drive caused by the use of an incorrect power supply, the device incorporates a power protection feature. If the user attempts to connect an incompatible power source, automatic protection will be enabled.

Better Protection

Features an intelligent, low-noise, and temperature-controlled fan. The fan speed adjusts automatically based on your hard drive temperature, meaning that your device will always remain at the optimal working temperature.

Withstand Continuous, Long-Term, and High-Load Use

With its aluminum enclosure and low-noise fan, the D5-300 is firm and reliable, has good heat dissipation, and offers low noise. As a result, the device can withstand high-load operations for tens of hours.

Benefit From Diverse Applications

The D5-300 is a great companion for video editing, photo backups, R&D technical document storage, file backups, music libraries, financial records, video surveillance video storage, and commercial data storage.

Exclusive worry-free warranty

Brand new replacement for 2 years, quick service in 24 hours!



Storage:
Disk Slot Number 5
Compatible Disk Types 3.5″ SATA HDD
2.5″ SATA HDD
2.5″ SATA SSD
File System NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
Maximum Internal Raw Capacity 100TB (20 TB drive x 5) (Capacity will vary along with the RAID type)
RAIDs Supported Support RAID 0、RAID 1、RAID 5、RAID 10、CLONE、JBOD、Single Disk

Hardware RAID √
RAID Manager Software √
RAID Manager Software Language English, Chineses, Japanese, German, French, Spanish, Italian
RAID Online Expansion /
RAID Migration /
RAID Auto-rebuilding /
Drive Hot Swap /
HDD Sleep √
HDD S.M.A.R.T. Inspection /
Sector Inspection and Parity Check /
SSC Cache /
Daisy Chain /
HDD NCQ Technology /
Alert Notice /
Event Log /

External Ports:
USB USB3.1 Type-C gen1 x 1
Thunderbolt /
DP Interface /
Power Socket DC IN 12V
Reading/writing Speed (max.)
Reading Speed (max.) Read：210MB/s (2 SSHD RAID0 mode)
Writing Speed (max.) Write：190MB/s (2 SSHD RAID0 mode)

Appearance:
Size (H*W*D) 227 x 225 x 136 mm
Packaging Size (H*W*D) 300 x 275 x 186 mm
Weight Net Weight: 2.1Kg Gross Weight: 3.5Kg
Others
System fan 80 mm x 80 mm x25mm (x 2)
Fan mode Smart
Noise Level 19.8dB(A)
Power Supply
Power Supply 90W
AC Input Voltage 100V to 240V AC
Current Frequency 50/60 HZ, Single Phase
Power Consumption 45.6W(Access)

Environment Temperature:
Working Temperature 5°C ~ 40°C (40°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-5°F ~ 140°F)
Relative Humidity 5% ~ 95% RH
Supported OS Windows OS、Mac OS
Warranty 2 years
Certificate CE, FCC, CCC, KC
Environment RoHS compliance

Package Contents:
Host unit (x1)
Power cord (x1)
USB Cable A to Type-C (10Gb) 1 Meter (x1)
Quick Installation Guide (x1)
Power adapter (x1)
Screws (several)
Limited Warranty Note x 1
